4th gen F BODY camaro suspension

ls1sleeper

ls1sleeper

Club Member
need some picture/tips or pointers for a 99 camaro about to start ordering things i have a 9inch in the rear with a tunnel mounted torgue arm thats it. any info or pictures woould be appreciated

From what i have read, and understand.....it all depends on the direction you are going with the car....handling or hooking.

But:

Tires--most important aspect of either direction you are going
Frame ties--most people swear by them, others say not necessary, i deem it cheap insurance and needed strength.
Shocks-- important either way

Handling-- Sway bars, springs, panhard bar, properly setup shocks for springs used, LCA's and better bushings throughout, mtr/trans mounts.
Hooking-- Drag spring/shocks, panhard mainly to center rear end, and LCA's to prevent flexing of factory units.

LS1TECH.com has alot of info on the various setups and what works for guys, it will be alot of reading over there for ya, that's usually where i check.

Are you looking to hook at the track or just driving around town? Judging by your avatar I am guessing hooking. In which case most of what was mentioned above should cover you.

I second the subframe connectors. If you are making any kind of torque with your engine set-up they will drastically reduce body twist. I know because I was dimpling my rear fenders due to the torque the turbo's added. ;)

Lower control arms and relocation brackets will keep the rear planted. Sounds like you already have a drag torque arm bar. The tunnel mounted one was more for drag cars.

Pics are available on BMR, UMI, Spohn, etc websites. Not hard to find the parts and pics on cars.

i really just want ppictures to see how some fast fbody r done.

i got qa1 coilovers
relocation brakets
cage
subframe connectors
lca
short tunnel mounted T/A

like what is the top bar above the panhard bar? can i take that out?

got it sitting 28imches in the rear as to were I wanted it to be at. And now I just need front Coilovers

Sphon pro series TA, wolfe anti-roll , strange coil overs, leave the upper PHB support bar in, def get lca relocators

82bird said:
Sphon pro series TA, wolfe anti-roll , strange coil overs, leave the upper PHB support bar in, def get lca relocators
Click to expand...

I would not get the lca relocators. Not needed in my opinion. All BMR got me a 1.23 sixty ft. with AFCO's in the rear and QA1 up front.

My street car's been 1.48 60's with an airbag in the right rear, and preloading the stock rear sway bar. Also has LCA brackets, everything in the rear is tubular.
